IstaBreeze i-700W 12V/24V/48V Wind Turbine



  • 700w wind turbine
  • 700w wind turbine-2
  • 700w wind turbine-3
  • 700w wind turbine-4
  • 700w wind turbine-5
  • 700w wind turbine-6
  • 700w wind turbine
  • 700w wind turbine-2
  • 700w wind turbine-3
  • 700w wind turbine-4
  • 700w wind turbine-5
  • 700w wind turbine-6


Product Description:



  • Our world leading range of iSTA-BREEZE® Ideal for camping, garden and home use.

    • Universal application for low, middle and high wind
    • 3-phase permanent magnets (High efficiency due to strong permanent magnets (NdFeB magnets, 150 ° temperature resistant)
    • Aerodynamic design
    • Powder coated aluminum alternator
    • Low noise
    • UV-resistant Plastic + 30% glass fibers blades, successfully tested
    • Power transmission through slip ring, thereby no twisting of the cable possible Durable and low maintenance
  performance chart  instruction  seko





detay1









PRODUCT FEATURES - WIND TURBINE
Current
60A (12V) - 30A (24V) - 15A (48V)
Alternator Body
Aluminium
Body Material
Aluminium-Casting
Maximum Power
800W
Rated Power
700W

   Voltage

   12V-AC / 24V-AC / 48V-AC

   Package Dimensions

   1.Package: 60 x 40 x 30 cm (15 kg) 2.Package: 110 x 19 x 12 cm (3 kg) Totaly: 18 kg
WIND SPEED
Initial Wind Speed
3 m/s
Maximum Wind Speed
14-15 m/s
BLADE SPECIFICATION
Blade Material
Composite
Blade Length
90 cm
Rotor Diameter
186 cm
Noise
40 dB

   Weight

   620 Gr

   Width

   14,3 cm
NECESSARY EQUIPMENTS

Battery
Suitable battery group: Min 2400W - Max 4800W
PACKAGE CONTENT
Connection Screws
1 Set
Nose
1 Pc
Flange
    1 Pc
Generator
    1 Pc
Blades
    3 Pcs
Manual Book
    1 Pc

  Tail - Tail Pipe

    1 Pc
